Example Designs
The example designs for the Ethernet FMC Max are hosted on Github.
| Example Designs | |||
|---|---|---|---|
| AXI 1G Ethernet Example Design | More info | Git repo | Docs |
Note that all of our example designs were developed using Xilinx software tools and the
Xilinx AXI Ethernet Subsystem IP. If you wish to use these example designs, you must at least
have an evaluation license for the Xilinx TEMAC IP. See instructions on
obtaining a license here.
AXI 1G Ethernet Subsystem based example
Description
This example design is based on Xilinx’s soft MAC (ie. FPGA implemented), the AMD Xilinx AXI 1G/2.5G Ethernet Subsystem IP , that can be found in the Vivado IP Catalog. As the MAC is implemented in the FPGA fabric, this example is ideal for pure FPGA designs or Zynq/ZynqMP designs that require some packet processing to be performed in the FPGA.
Links
Block diagram
PS GEM based example
Description
This example design utilizes the Gigabit Ethernet MACs (GEMs) that are embedded into the Processing System (PS) of the Zynq 7000™ and Zynq Ultrascale+™ devices. The embedded MACs used in this example design do not use up any of the FPGA fabric, which makes it ideal for applications that need to use the FPGA for other purposes.
Links
- Coming soon
